iCircuit

This small update fixes the D12 port label on Arduino Nanos # Version 1.5 Updates This major update brings powerful new analysis tools, expanded microcontroller support, and numerous improvements. ## Bode Plot Analysis Unlock frequency response analysis with new Bode plot capabilities! Visualize how your circuits respond across frequencies with magnitude and phase plots. Perfect for analyzing filters, amplifiers, and frequency-dependent circuits. See cutoff frequencies, gain characteristics, and phase relationships at a glance. ## Expanded Microcontroller Support - **AC Motor** - Single phase AC induction motor - **Arduino Mega** - Build bigger projects with 54 digital I/O pins and 16 analog inputs - **Arduino Nano** - Compact board ideal for small-scale applications - **ESP32 and ESP8266** - Enhanced support for popular IoT microcontrollers ## New Circuit Elements - **Barrel Connector** - Professional DC power jack for your circuits with configurable shunt terminal - **Improved Power Supply Jack** with better connection handling ## Quick Search Find circuit elements faster than ever! New search bar lets you instantly locate components without scrolling through categories. Just start typing and get to building. ## Voltage Monitoring Protect your circuits with automatic under-voltage and over-voltage warnings. Get notified when components are operating outside their safe voltage ranges, helping prevent damage to sensitive ICs and ensuring reliable operation. ## Element Library Organization - New Microcontroller category for better organization - Improved element filtering options - Elements sorted by Pro availability for easier discovery ## UI Improvements - Completely redesigned toolbar optimized for macOS Sequoia - Unified window style with transparent titlebar for more workspace - Better trackpad gesture support including improved zoom and pan - Enhanced inspector with safe area support - Enhanced zoom controls for precise circuit work ## Bug Fixes - Fixed photodiode and photoresistor light source selection - Removed false capacitor loop errors that prevented valid circuits from running - Added input voltage tolerance for digital ICs to prevent spurious warnings from minor voltage fluctuations - Better handling of Arduino EEPROM and multiple board types Thank you for your continued support! Whether you're learning electronics, prototyping professional designs, or just having fun building circuits, we hope v1.15 makes your experience even better.
